HG114 Tube Mill

1. Summary

The mill is intended for manufacturing of round pipe of Φ50mm-Φ114mm with thickness of 2.0mm–5.0mm from cold-rolled and hot-rolled coil strip by means of unclosed tubular blank with its subsequent welding into tube, edge heating by means of solid state high-frequency welder, longitudinal seam welding in rolls of tube welding machine, cooling, further sizing or shaping and on-stream cutting of endless tube in measured lengths.

2. Raw material: hot rolled coil or cold rolled coil slitted in suitable width, Q195, Q235;

3. The technical flow of the production line

{SteelTape}→→ Single-arbor un-coiler →→Strip-head Cutter and welder→→

Spiral Accumulator→→Forming section (Flattening unit +Main driving unit +Forming unit +Guide unit +High frequency induction welding unit +squeeze roller) + De-burr frame→→Cooling unit →→ Sizing section →→Flying saw→→Rollout conveyor→→ Straightening Machine→→pipe end facing & chamfering→→Hydro Tester →→Packing box

4. Products:

Carbon steel tube as per customer’s request:

5. Line Speed                 : 30-70m/min

6. Power Source

7. Cooling water
